12 WAY DB TPN (HAVELLS)
12 WAY DB TPN (HAVELLS)
Regular price
GH₵2,875.00
Sale price
GH₵2,875.00
Unit price
per
Light bulb sold separately
SKU: SKU: 711-42154 EAN:| EAN:
Low stock: 1 available
Couldn't load pickup availability
Liquid error (snippets/sticky-add-to-cart line 11): invalid url input
12 WAY DB TPN (HAVELLS)
Default Title
Couldn't load pickup availability
Delivery within 1-2 working days
15 day returns. 30 days for members. Register
Description
Description
The Havells 12-Way TPN DB features an extended, premium vertical double-door enclosure engineered from high-grade cold rolled close annealed (CRCA) sheet steel. The unit is coated in Havells' signature dual-tone Pearl Ivory and Mineral Grey powder finish, which offers superior defense against structural impacts, scratches, and chemical corrosion.
The internal configuration is built to manage massive multi-phase power loads by systematically breaking a primary three-phase incoming supply into separate branch paths. The top compartment accommodates an industrial-sized 3-phase or 4-pole incomer breaker (such as a molded case circuit breaker (MCCB), Isolator, or residual current circuit breaker (RCCB)). This feeds power down through three color-coded, heavily insulated tin-plated copper busbars. The lower section houses extended DIN rails that accept up to 12 independent sets of outgoing triple-pole circuit breakers (amounting to 36 single-pole modules), completely supported by heavy-duty isolated neutral terminal banks and grounding links.
Technical Specifications
| Parameter | Specification Details |
|---|---|
| Brand | Havells |
| Configuration | 12 Way TPN (Triple Pole + Neutral / 3-Phase Layout) |
| Door Configuration | Double Door (DD) with Flush Mechanical Push-Latch Handle |
| Chassis Material | High-Grade, Corrosion-Resistant Powder-Coated CRCA Steel |
| Color & Finish | Premium Dual-Tone Pearl Ivory / Mineral Grey |
| Busbar Current Rating | 100 A Max Continuous Operating Current |
| Busbar Short-Circuit | 5 kA for 100 ms |
| Rated Voltage & Supply | 240V / 415V AC, 50 Hz 3-Phase Supply Systems |
| IP Enclosure Protection | IP42 (Protected against solid tools >1mm and vertical dripping moisture) |
| Mounting Installation | Universal Flush (Recessed Wall Cutout) or Surface Mounted |
| Standards Compliance | IS 8623 / IEC 61439-3 Certified |
Application and Best Uses
The high module capacity of the 12-way TPN configuration makes it an exceptional centralized power distribution hub for extensive, heavy-load properties.
- Commercial Centers & Malls: Perfect for coordinating complex retail zones, systematically partitioning independent power lines for storefront spotlight tracks, registers, and individual tenant sub-meter panels.
- Medium Industrial Factories: Used inside workshops and light manufacturing spaces to cleanly deliver stable three-phase power lines straight to heavy stationary machinery while keeping general lighting breakers fully isolated.
- Large Office Complexes: Highly efficient for multi-department floors to split electrical branch feeds, providing dedicated, phase-balanced circuits to server rooms, climate control units, and dense worker desktop arrays.
- Institutional & Public Facilities: Ideal for high-density public structures such as hospital wings, university laboratory grids, and hotels to safely segregate power demands across separate wings or facility floors.
Specifications
Description
The Havells 12-Way TPN DB features an extended, premium vertical double-door enclosure engineered from high-grade cold rolled close annealed (CRCA) sheet steel. The unit is coated in Havells' signature dual-tone Pearl Ivory and Mineral Grey powder finish, which offers superior defense against structural impacts, scratches, and chemical corrosion.
The internal configuration is built to manage massive multi-phase power loads by systematically breaking a primary three-phase incoming supply into separate branch paths. The top compartment accommodates an industrial-sized 3-phase or 4-pole incomer breaker (such as a molded case circuit breaker (MCCB), Isolator, or residual current circuit breaker (RCCB)). This feeds power down through three color-coded, heavily insulated tin-plated copper busbars. The lower section houses extended DIN rails that accept up to 12 independent sets of outgoing triple-pole circuit breakers (amounting to 36 single-pole modules), completely supported by heavy-duty isolated neutral terminal banks and grounding links.
Technical Specifications
| Parameter | Specification Details |
|---|---|
| Brand | Havells |
| Configuration | 12 Way TPN (Triple Pole + Neutral / 3-Phase Layout) |
| Door Configuration | Double Door (DD) with Flush Mechanical Push-Latch Handle |
| Chassis Material | High-Grade, Corrosion-Resistant Powder-Coated CRCA Steel |
| Color & Finish | Premium Dual-Tone Pearl Ivory / Mineral Grey |
| Busbar Current Rating | 100 A Max Continuous Operating Current |
| Busbar Short-Circuit | 5 kA for 100 ms |
| Rated Voltage & Supply | 240V / 415V AC, 50 Hz 3-Phase Supply Systems |
| IP Enclosure Protection | IP42 (Protected against solid tools >1mm and vertical dripping moisture) |
| Mounting Installation | Universal Flush (Recessed Wall Cutout) or Surface Mounted |
| Standards Compliance | IS 8623 / IEC 61439-3 Certified |
Application and Best Uses
The high module capacity of the 12-way TPN configuration makes it an exceptional centralized power distribution hub for extensive, heavy-load properties.
- Commercial Centers & Malls: Perfect for coordinating complex retail zones, systematically partitioning independent power lines for storefront spotlight tracks, registers, and individual tenant sub-meter panels.
- Medium Industrial Factories: Used inside workshops and light manufacturing spaces to cleanly deliver stable three-phase power lines straight to heavy stationary machinery while keeping general lighting breakers fully isolated.
- Large Office Complexes: Highly efficient for multi-department floors to split electrical branch feeds, providing dedicated, phase-balanced circuits to server rooms, climate control units, and dense worker desktop arrays.
- Institutional & Public Facilities: Ideal for high-density public structures such as hospital wings, university laboratory grids, and hotels to safely segregate power demands across separate wings or facility floors.
