3VTB-2B32 Breaker 2P 32A 3KA B-C (VIKO)
3VTB-2B32 Breaker 2P 32A 3KA B-C (VIKO)
SKU: SKU: 612-36025 EAN:| EAN:
In stock. 19 available
Couldn't load pickup availability
Couldn't load pickup availability
Delivery within 1-2 working days
15 day returns. 30 days for members. Register
Description
The VIKO 3VTB-2B32 is a 2-pole miniature circuit breaker (MCB) designed for electrical protection against overloads and short circuits in residential or commercial systems.
- Model Number: 3VTB-2B32
- Poles: 2P (Double Pole)
- Rated Current (Amperage): 32A
- Breaking Capacity: 3kA (3,000A) at 230/400V AC
-
Tripping Curve: Type B
- Note: Type B breakers are sensitive and typically trip when the current reaches 3 to 5 times the rated load, making them suitable for domestic applications and circuits with low inrush currents.
- Rated Insulation Voltage (Ui): 500V
- Impulse Withstand Voltage (Uimp): 4kV
- Protection Class: IP20 (protection against fingers and solid objects over 12mm)
- Operating Life: Approximately 4,000 electrical cycles and 8,000 mechanical cycles.
- Safety Design: Includes 12-plate cell structure to extinguish electrical arcs effectively.
- Terminals: Designed with high protection against accidental contact.
- Efficiency: Engineered for low power consumption to support energy savings.
Specifications
The VIKO 3VTB-2B32 is a 2-pole miniature circuit breaker (MCB) designed for electrical protection against overloads and short circuits in residential or commercial systems.
- Model Number: 3VTB-2B32
- Poles: 2P (Double Pole)
- Rated Current (Amperage): 32A
- Breaking Capacity: 3kA (3,000A) at 230/400V AC
-
Tripping Curve: Type B
- Note: Type B breakers are sensitive and typically trip when the current reaches 3 to 5 times the rated load, making them suitable for domestic applications and circuits with low inrush currents.
- Rated Insulation Voltage (Ui): 500V
- Impulse Withstand Voltage (Uimp): 4kV
- Protection Class: IP20 (protection against fingers and solid objects over 12mm)
- Operating Life: Approximately 4,000 electrical cycles and 8,000 mechanical cycles.
- Safety Design: Includes 12-plate cell structure to extinguish electrical arcs effectively.
- Terminals: Designed with high protection against accidental contact.
- Efficiency: Engineered for low power consumption to support energy savings.
