Description
The VIKO 3VTB-3B25 Miniature Circuit Breaker (MCB) is a three-pole electrical protection device designed by Panasonic to safeguard low-voltage networks from overloads and short circuits.
- Poles: 3P (Triple Pole)
- Rated Current (In): 25A
- Breaking Capacity: 3kA (3,000 Amperes)
- Tripping Curve: B-Type (typically trips between 3 to 5 times the rated current)
- Rated Voltage (Un): 400V~
- Protective Function: Specifically engineered to protect against overload and short-circuiting risks in three-phase electrical systems.
- High-Speed Mechanism: Features a high-speed tripping mechanism to instantly disconnect power during a fault, preventing damage to downstream equipment.
- Status Indicators: Includes clear mechanical ON/OFF indicators for easy visual diagnosis of circuit status.
- Mounting: Designed for standard 35mm DIN rail installation in modular distribution boxes.
- Three-Phase Motors: For small industrial machinery or commercial HVAC units.
- Sub-Distribution Boards: In large residential or commercial buildings.
- Professional Kitchens: Protecting heavy-duty electrical equipment.
Specifications
The VIKO 3VTB-3B25 Miniature Circuit Breaker (MCB) is a three-pole electrical protection device designed by Panasonic to safeguard low-voltage networks from overloads and short circuits.
- Poles: 3P (Triple Pole)
- Rated Current (In): 25A
- Breaking Capacity: 3kA (3,000 Amperes)
- Tripping Curve: B-Type (typically trips between 3 to 5 times the rated current)
- Rated Voltage (Un): 400V~
- Protective Function: Specifically engineered to protect against overload and short-circuiting risks in three-phase electrical systems.
- High-Speed Mechanism: Features a high-speed tripping mechanism to instantly disconnect power during a fault, preventing damage to downstream equipment.
- Status Indicators: Includes clear mechanical ON/OFF indicators for easy visual diagnosis of circuit status.
- Mounting: Designed for standard 35mm DIN rail installation in modular distribution boxes.
- Three-Phase Motors: For small industrial machinery or commercial HVAC units.
- Sub-Distribution Boards: In large residential or commercial buildings.
- Professional Kitchens: Protecting heavy-duty electrical equipment.
