The Sv-k LED SQ PANEL 30W 6000K WHITE (TEKLED) is a high-efficiency recessed square ceiling panel downlight. It features a heavy-duty passive thermal management layout engineered to deliver powerful, crisp daylight visibility inside suspended false ceiling grids.
Technical Specifications
-
Light Source Type: Integrated high-density SMD LED matrix board.
-
Power Output: 30W power consumption baseline.
-
Color Temperature: 6000K (Crisp Cool Daylight White spectrum for maximum contrast).
-
Housing Body Material: Rugged die-cast aluminum alloy square chassis.
-
Passive Cooling System: Extended, multi-segmented vertical radiator fin channels lining the outer perimeter base.
-
Finish Color: Electrostatic powder-coated smooth White outer frame.
-
Diffuser Mask: Flat, high-transmittance frosted opal polycarbonate panel lens.
- Installation Method: Recessed layout, flush-integrated into false ceiling plates by means of side-clamping tension spring clips.
Structural & Passive Thermal Engineering
-
Peripheral Fin Radiator: The continuous array of deep vertical aluminum cooling track slots maximizes surface area contact. This architecture rapidly draws core heat away from the internal LED node chips to maintain driver stability.
-
Unified Illumination Canvas: The premium frosted white panel diffuser completely blends individual raw chip hotspots, outputting a uniform, soft sheet of downward light across the room layout.
Core Application Placements
-
Central ambient ceiling illumination for large commercial offices, conference halls, exhibition kiosks, and corporate workspaces.
-
High-visibility task lighting setups inside schools, hospital wards, medical pathways, and banking halls.
-
Modern minimalist recessed downlighting for residential living rooms, wide kitchens, store showrooms, and restaurant dining areas.
