MCB NXB-63 1P C6 6KA(UCT)

Name: MCB NXB-63 1P C6 6KA(UCT)
Brand: TEKLED GH
SKU: 990-101-0025
Price: 35.00 GHS
Availability: OutOfStock

GH₵35.00

0% off Sold out

Light bulb sold separately

SKU: SKU: 990-101-0025 EAN:| EAN:

Out of stock

Liquid error (snippets/sticky-add-to-cart line 11): invalid url input

MCB NXB-63 1P C6 6KA(UCT)

Default Title

Delivery within 1-2 working days
15 day returns. 30 days for members. Register

View full details

The MCB NXB-63 1P C6 6kA is a high-performance, single-pole (1P) miniature circuit breaker engineered for reliable final-stage power distribution systems. It functions as a safety switch by continuously monitoring electrical paths and automatically disconnecting the load during fault events.

Dual-Layer Protection: Employs a thermal-magnetic release mechanism, utilizing a bimetallic strip for time-delayed overload protection and an electromagnetic coil for instant short-circuit isolation.
Positive Isolation: Incorporates a mechanical indicator windows (green/red) linked directly to the internal contacts, ensuring verified contact disconnection for safer downstream servicing.

Specifications

Parameter	Specification / Rating
Brand & Series	MCB NXB-63
Number of Poles	1P (Single Pole - manages 1 phase)
Rated Current	6A (Optimized for minor commercial and residential sub-circuits)
Tripping Curve / Characteristic	Type C (Trips instantly between 5 to 10 times the rated current)
Rated Short-Circuit Capacity	6,000A (6kA)
Rated Service Breaking Capacity	6,000A (6kA)
Rated Operating Voltage	220V / 230V / 240V AC
Rated Insulation Voltage	500V
Rated Impulse Withstand Voltage	4kV
Rated Frequency	50 / 60 Hz
Mechanical Lifespan	≥ 20,000 operations
Electrical Lifespan	≥ 10,000 operations
Standard Compliance	IEC / EN 60898-1
Mounting Mechanism	Standard 35mm DIN Rail (TH35-7.5)
Terminal Connection Capacity	1mm² to 25mm² solid or flexible wiring
Ingress Protection (IP) Rating	IP20 (Standalone) / IP40 (Housed in an enclosure)

Application

The Type C trip curve combined with a 6A rating makes this single-pole circuit breaker exceptionally suited for environments that handle mild, brief inrush currents without triggering nuisance tripping.

Residential & Commercial Lighting: Ideal for safeguarding dedicated LED, fluorescent, or incandescent lighting loops where startup currents spike briefly.
Low-Power Equipment & Sub-circuits: Commonly used to isolate and protect general-use convenience wall sockets, control loops, office hardware, and light household appliances.
Industrial Control Panels: Acts as auxiliary overcurrent protection for PLC power modules, sensor circuits, and tiny ventilation fans within primary control structures.

Dual-Layer Protection: Employs a thermal-magnetic release mechanism, utilizing a bimetallic strip for time-delayed overload protection and an electromagnetic coil for instant short-circuit isolation.
Positive Isolation: Incorporates a mechanical indicator windows (green/red) linked directly to the internal contacts, ensuring verified contact disconnection for safer downstream servicing.
