SENSOR FOR 224-03272 PROZHEKTORLED COB 50W (TEKLED)

The PIR (Passive Infrared) Motion Sensor Module for 50W LED Floodlights is a compact, highly responsive environmental tracking switch engineered to automate outdoor security luminaires. Constructed with a heavy-duty, UV-stabilized black polycarbonate shell, this specialized sensor module mounts directly to the base of commercial floodlights via a threaded swivel arm, ensuring full multidirectional rotational adjustments for maximum area coverage.

• Detection Technology: Dual-element Passive Infrared (PIR) thermal wave sensing system.
• Electrical Load Compatibility: Optimized to drive 50W LED floodlights (handles inductive loads up to 100W or resistive loads up to 500W).
• Operating Mains Threshold: Standard 220V–240V AC, 50/60Hz system compatibility.
• Sensing Range Geometry: Wide 120^o horizontal detection arc spanning a distance threshold of 5 to 12 meters (adjustable based on surrounding ambient temperatures).
• Time-Delay Calibration: Fully adjustable hold-time slider typically ranging from 10 seconds (±5s) up to 7 minutes (±2min).
• Daylight Control (Lux Tracking): Integrated adjustable photocell threshold from 3 Lux (strict nighttime-only automation) to 2000 Lux (all-day operation).
• Ingress Protection (IP): IP45 or IP65 rated (sealed with rubberized internal O-rings to survive heavy wind, dust, and multi-directional rainfall weathering when properly aimed downward).
• Hardware Integration: Threaded metal or structural polymer lock-nut connector with a pre-wired 3-core fly-lead (Live, Neutral, and Switched Output).

• Residential Perimeter Defense: Automated to flood dark garage ports, front entrance porches, back alleys, and garden walkways with instant light the moment motion is detected, deterring potential intruders.
• Commercial Loading Docks & Warehouses: Handles automated hands-free illumination across industrial freight entryways, delivery corridors, and exterior vehicle parking bays during nighttime operations.
• Energy-Efficient Walkways: Lowers active energy bills across communal spaces, hotel side-paths, and apartment complexes by ensuring high-power 50W floodlights trigger only when a resident or vehicle enters the zone.
• Industrial Perimeter Fences: Deployed alongside property boundary walls and security guard checkpoints to flag physical movements across vulnerable entry zones.

1. SENS (Sensitivity): Tunes the distance perimeter of the sensor to prevent false triggers from small animals, wind-blown vegetation, or distant street traffic.
2. TIME (Hold Time): Configures exactly how long the connected 50W floodlight will remain illuminated after all physical motion has ceased in the detection zone.
3. LUX (Daylight Sensor): Adjusts the light threshold level to prevent the 50W floodlight from switching on during bright daylight hours when natural sunlight is sufficient.
