VTC-18/10/S AC CONTACTOR 18A 1NO 230V(VIKO)
VTC-18/10/S AC CONTACTOR 18A 1NO 230V(VIKO)
Regular price
GH₵176.00
Sale price
GH₵176.00
Unit price
per
Light bulb sold separately
SKU: SKU: 620-36018 EAN:| EAN:
In stock. 17 available
Couldn't load pickup availability
Liquid error (snippets/sticky-add-to-cart line 11): invalid url input
VTC-18/10/S AC CONTACTOR 18A 1NO 230V(VIKO)
Default Title
Couldn't load pickup availability
Delivery within 1-2 working days
15 day returns. 30 days for members. Register
Description
The Viko VTC-18/10/S is a high-quality 3-pole power contactor designed for the automatic control of electrical systems. It is primarily used to manage motors, heating, and industrial lighting by safely switching high currents via a control signal.
Technical Specifications
- Brand: VIKO (Panasonic Group)
- Model Code: VTC-18/10/S-SN2
- Rated Current: 18A
- Rated Power (AC3): 7.5 kW (at 380/400V)
- Coil Voltage: 230V AC (50/60Hz)
- Pole Configuration: 3P (3 Main Power Poles)
- Auxiliary Contacts: 1NO (One Normally Open integrated auxiliary contact)
- Mounting: Compatible with standard 35mm DIN rail or panel mounting
Key Features
- Compact Design: Designed to save space within electrical distribution boards and control panels.
- Quiet Operation: Features low-noise switching, making it suitable for both commercial and residential environments.
- Durability: High-conductivity contact surfaces ensure minimal heating and a long operational lifespan under heavy loads.
- Expandability: Supports the addition of auxiliary contact blocks or timers to extend control functionality.
Specifications
The Viko VTC-18/10/S is a high-quality 3-pole power contactor designed for the automatic control of electrical systems. It is primarily used to manage motors, heating, and industrial lighting by safely switching high currents via a control signal.
Technical Specifications
- Brand: VIKO (Panasonic Group)
- Model Code: VTC-18/10/S-SN2
- Rated Current: 18A
- Rated Power (AC3): 7.5 kW (at 380/400V)
- Coil Voltage: 230V AC (50/60Hz)
- Pole Configuration: 3P (3 Main Power Poles)
- Auxiliary Contacts: 1NO (One Normally Open integrated auxiliary contact)
- Mounting: Compatible with standard 35mm DIN rail or panel mounting
Key Features
- Compact Design: Designed to save space within electrical distribution boards and control panels.
- Quiet Operation: Features low-noise switching, making it suitable for both commercial and residential environments.
- Durability: High-conductivity contact surfaces ensure minimal heating and a long operational lifespan under heavy loads.
- Expandability: Supports the addition of auxiliary contact blocks or timers to extend control functionality.
