VTR2-2530 UZO RCCB 2P 25A 30MA (VIKO)
VTR2-2530 UZO RCCB 2P 25A 30MA (VIKO)
Regular price
GH₵176.00
Sale price
GH₵176.00
Unit price
per
Light bulb sold separately
SKU: SKU: 616-36225 EAN:| EAN:
Low stock: 4 available
Couldn't load pickup availability
Liquid error (snippets/sticky-add-to-cart line 11): invalid url input
VTR2-2530 UZO RCCB 2P 25A 30MA (VIKO)
Default Title
Couldn't load pickup availability
Delivery within 1-2 working days
15 day returns. 30 days for members. Register
Description
The VIKO VTR2-2530 2P 25A 30mA RCCB / UZO Residual Current Circuit Breaker is a professional-grade modular electrical safety device. It functions as a rapid protection sentinel, continuously monitoring current balance between the phase and neutral lines to instantly disconnect the power supply in the event of a dangerous current leakage.
Technical Specifications
- Model Series Designation: VTR2 Series (VTR2-2530)
- Breaker Device Type: RCCB / UZO (Residual Current Circuit Breaker)
- Number of Poles: 2-Pole (2P / Single Phase + Neutral)
- Rated Current Capacity (In): 25A
- Rated Operating Voltage (Un): 230V AC
- Residual Operating Current (I∆n): 30mA (High Sensitivity / Life Protection Threshold)
- Short-Circuit Breaking Capacity: 6kA standard resilience tracking
- Detection Leakage Type: Type AC (Sensitive strictly to alternating residual sinusoidal currents)
- Mounting Configuration: Standard 35mm DIN-Rail modular attachment
- Ingress Protection Level: IP20 terminal finger-touch safety rating
Product Description
- 30mA Human Life Protection: Specifically calibrated to trip immediately if a leakage current exceeding 30mA is identified. This rapid-response mechanism interrupts power before electrical shocks can cause severe physiological harm or heart fibrillation.
- Dedicated Test Facility: Outfitted with a prominent grey rectangular "T" (Test Monthly) push-button on the front casing. Pressing this systematically simulates an internal leakage path, allowing home users to safely verify the mechanical health and responsiveness of the trip mechanism.
- High-Visibility Status Indicator: Features a dual-color status notification flag directly above the primary toggle switch rocker, displaying a clear green "O-OFF" or red "I-ON" tag for instant circuit diagnosing.
- Shielded Screw Terminal Boxes: Engineered with isolated, heavy-gauge screw clamps designed to accommodate standard single-core wires, stranded cables, or comb-pin busbars while protecting installers from accidental terminal touch.
Primary Applications
- Residential Consumer Units: Installed inside main apartment or villa distribution board boxes to manage downstream branch circuits.
- Bathroom & Damp Zone Protection: Mandatory requirement for safeguarding power feeds routed to washing machines, electric water heaters, and grooming vanity areas where water contact risks are elevated.
- Commercial Office Hubs: Utilized to protect staff member workstations, office lighting routes, and communal kitchenettes from insulation breakdowns or wire faults.
Specifications
The VIKO VTR2-2530 2P 25A 30mA RCCB / UZO Residual Current Circuit Breaker is a professional-grade modular electrical safety device. It functions as a rapid protection sentinel, continuously monitoring current balance between the phase and neutral lines to instantly disconnect the power supply in the event of a dangerous current leakage.
Technical Specifications
- Model Series Designation: VTR2 Series (VTR2-2530)
- Breaker Device Type: RCCB / UZO (Residual Current Circuit Breaker)
- Number of Poles: 2-Pole (2P / Single Phase + Neutral)
- Rated Current Capacity (In): 25A
- Rated Operating Voltage (Un): 230V AC
- Residual Operating Current (I∆n): 30mA (High Sensitivity / Life Protection Threshold)
- Short-Circuit Breaking Capacity: 6kA standard resilience tracking
- Detection Leakage Type: Type AC (Sensitive strictly to alternating residual sinusoidal currents)
- Mounting Configuration: Standard 35mm DIN-Rail modular attachment
- Ingress Protection Level: IP20 terminal finger-touch safety rating
Product Description
- 30mA Human Life Protection: Specifically calibrated to trip immediately if a leakage current exceeding 30mA is identified. This rapid-response mechanism interrupts power before electrical shocks can cause severe physiological harm or heart fibrillation.
- Dedicated Test Facility: Outfitted with a prominent grey rectangular "T" (Test Monthly) push-button on the front casing. Pressing this systematically simulates an internal leakage path, allowing home users to safely verify the mechanical health and responsiveness of the trip mechanism.
- High-Visibility Status Indicator: Features a dual-color status notification flag directly above the primary toggle switch rocker, displaying a clear green "O-OFF" or red "I-ON" tag for instant circuit diagnosing.
- Shielded Screw Terminal Boxes: Engineered with isolated, heavy-gauge screw clamps designed to accommodate standard single-core wires, stranded cables, or comb-pin busbars while protecting installers from accidental terminal touch.
Primary Applications
- Residential Consumer Units: Installed inside main apartment or villa distribution board boxes to manage downstream branch circuits.
- Bathroom & Damp Zone Protection: Mandatory requirement for safeguarding power feeds routed to washing machines, electric water heaters, and grooming vanity areas where water contact risks are elevated.
- Commercial Office Hubs: Utilized to protect staff member workstations, office lighting routes, and communal kitchenettes from insulation breakdowns or wire faults.
